Gate Casambi LED Indicators

The module has 4 LEDs on the front. From bottom to top:

1. Operating LED
   Flashes green every 1 second when the device is connected and functioning correctly.
2. Network status
   - Lights yellow when the network is plugged in and stays on while connected to the network.
   - Turns off if the network is disconnected but the device is still powered via PoE.
3. UDP LED
   - Lights red when there is no UDP connection.
   - Lights green when a UDP connection is established.
   Note: This LED may take up to 60 seconds to display status after a restart.
4. TCP/IP LED
   - Lights red when there is no TCP/IP connection.
   - Lights green when a TCP/IP connection has been opened.
   Note: This LED may take up to 60 seconds to display status after a restart.


When powering on the Gate Casambi, LEDs 3 (UDP) and 4 (TCP/IP) light up red, while LEDs 1 and 2 remain off. Gradually, the rest of the LEDs turn on, and the UDP LED (3) changes to green, since the device communicates via the UDP protocol.

Additional Information

Performing a "Locate" action on the device displays a blue, green and purple pattern across the LEDs.
